Dia(inch)

Dia(mm)

Circ.(inch)

Weightkg/200m

Weight(lb/600ft)

UNSPLICED MBL(ton)

UNSPLICED MBL(kN)

LDBF, SPLICED MBL(ton)

LDBF, SPLICED MBL(kN)

1-9/16

40

5

191

385

42.0

411.6

7.2

32.1

1-3/4

44

5-1/2

234

470

50.4

493.9

45.3

38.6

1-25/32

45

5-5/8

245

494

52.6

516.2

47.4

40.2

1-7/8

48

6

277

558

58.2

570.3

52.3

44.5

2

50

6-1/4

301

607

63.1

618.5

56.8

48.3

2-1/6

52

6-1/2

328

661

67.8

664.4

61.0

51.9

2-5/32

55

6-7/8

367

740

75.8

743.2

68.2

58.0

2-1/4

56

7

380

760

76.6

752.0

69.1

60.6

2-3/8

60

7-1/2

438

883

86.4

846.7

77.7

66.1

2-1/2

64

8

498

1002

99.0

970.2

89.1

75.7

2-9/16

65

8-1/8

513

1035

102.0

999.6

91.8

78.0

2-11/16

68

8-1/2

561

1132

111.6

1093.6

100.4

85.4

2-3/4

70

8-3/4

596

1202

118.2

1158.3

106.3

90.4

2-7/8

72

9

631

1273

122.4

1199.5

110.1

93.6

2-31/32

75

9-3/8

683

1378

132.7

1300.6

119.4

101.5

3-5/32

80

10

777

1566

150.0

1470.0

135.0

114.8

3-3/8

85

10-5/8

875

1765

169.2

1658.1

152.2

129.4

3-7/16

88

11

937

1889

177.6

1740.4

159.8

135.9

3-9/16

90

11-1/4

980

1977

185.7

1820.4

168.1

142.1

3-3/4

95

11-7/8

1092

2202

206.8

2027.4

186.1

158.2

3-13/16

96

12

1103

2224

207.6

2034.4

186.8

158.8

4

100

12-1/2

1197

2415

225.2

2207.3

22.7

172.3

4-1/8

104

13

1298

2618

246.0

2410.8

221.4

188.2

4-3/20

105

13-1/8

1323

2669

250.6

2456.6

225.6

191.7

4-5/16

110

13-3/4

1452

2929

264.4

2591.9

238.0

202.3

4-7/16

112

14

1505

3036

270.0

2646.0

243.0

206.6

4-9/16

115

14-3/8

1587

3201

284.6

2789.4

256.1

217.7

4-3/4

120

15

1728

3486

309.8

3036.4

278.8
