Dia(inch)

Dia(mm)

Circ.(inch)

Weightkg/200m

Weight(lb/600ft)

UNSPLICED MBL(ton)

UNSPLICED MBL(kN)

LDBF, SPLICED MBL(ton)

LDBF, SPLICED MBL(kN)

1-9/16

40

5

198

400

42.0

411.6

37.8

32.1

1-3/4

44

5-1/2

240

484

50.4

493.9

45.3

38.6

1-7/8

48

6

284

572

58.2

570.3

52.3

44.5

2

50

6-1/4

308

621

63.1

618.5

56.8

48.3

2-1/6

52

6-1/2

332

669

67.8

664.4

61.0

51.9

2-5/32

55

6-7/8

372

750

75.8

743.2

68.2

58.0

2-1/4

56

7

400

806

76.6

752.0

69.1

60.6

2-3/8

60

7-1/2

445

898

86.4

846.7

77.7

66.1

2-1/2

64

8

504

1015

99.0

970.2

89.1

75.7

2-9/16

65

8-1/8

520

1048

102.0

999.6

91.8

78.0

2-3/4

70

8-3/4

603

1216

118.2

1158.3

106.3

90.4

2-7/8

72

9

660

1330

122.4

1199.5

110.1

93.6

2-31/32

75

9-3/8

716

1443

132.7

1300.6

119.4

101.5

3-5/32

80

10

800

1613

150.0

1470.0

135.0

114.8

3-3/8

85

10-5/8

903

1820

169.2

1658.1

152.2

129.4

3-7/16

88

11

954

1922

177.6

1740.4

159.8

135.9

3-9/16

90

11-1/4

998

2012

185.7

1820.4

168.1

142.1

3-13/16

96

12

1136

2291

207.6

2034.4

186.8

158.8

4-1/8

104

13

1332

2685

246.0

2410.8

221.4

188.2

4-7/16

112

14

1544

3112

270.0

2646.0

243.0

206.6

4-3/4

120

15

1773

3574

309.8

3036.4

278.8

237.0
